T Style Conduit Body

T style conduit body serves as connectors for threaded conduits, particularly when the electrical pathway needs to change direction. They feature removable, gasketed covers that ensure a waterproof seal while also providing convenient access for activities such as pulling additional wires, inspections, and routine maintenance. These conduit bodies are compatible with pipes ranging in diameter from 3/4" to 2" and are constructed from AISI 316L stainless steel.

Send Inquiry

Product Description

Application:

T style conduit body is utilized to connect with threaded rigid or EMT conduits whenever a directional change is necessary. They feature a removable cover and gasket, facilitating easy wire pulling. These bodies are frequently employed as cost-effective convenience boxes when additional space for wires is required.

Advantages:

T style conduit bodies offer time and cost savings by avoiding the expensive process of bending large conduits to alter their direction. They enable installers to achieve smooth wire bends effortlessly. Featuring a powder-coated finish and a watertight gasket, they ensure a durable and weather-resistant installation. Moreover, their detachable cover facilitates straightforward and convenient maintenance as well as future wire pulling tasks.

Product Parameter

Surface treatment	Electrolytic polishing
Material	AISI 316L
Model	3/4'',1'',1 1/2'',2''
Technics	Casting
Feature	Malleable cover, fire resistant gaskets, stainless steel screws
Weight	0.97kg/1.23kg/2.39kg/3.51kg
